1  R

The R companion to this book is R Workflow which goes into much more detail and provides many examples of using R especially in the context of making a reproducible report. The material below provides an introduction to R Workflow.

1.1 Background

Computer code shown throughout these notes is R R Development Team (2020). R is free and is the most widely used statistical software in the world. It has the best graphics, statistical modeling, nonparametric methods, survival analysis, clinical trials methods, and data manipulation capabilities. R has the most comprehensive genomics analysis packages and has advanced capabilities for reproducible analysis and reporting. R also has an excellent graphical front-end RStudio (rstudio.org) that has the identical look and feel on all operating systems and via a web browser. Part of R’s appeal is the thousands of add-on packages available (at cran.r-project.org/web/packages), which exist because it is easy to add to R. Many of the add-on packages are specialty packages for biomedical research including packages for such widely diverse areas as

• interfacing R to REDCap (2 packages)
• interactive design of adaptive clinical trials
• analyzing accelerometer data
• flow cytometry
• genomics
• analyzing ICD9 codes and computing comorbidity indexes
• downloading all annotated NHANES datasets
• interfacing to clinicaltrials.gov
• detecting whether a dataset contains personal identifiers of human subjects
• analysis of early phase cardiovascular drug safety studies The main R web site is www.r-project.org.

1.2 Learning R

Start with R Tutorials at www.r-bloggers.com/how-to-learn-r-2, R Programming Tutorials from Mike Marin at www.youtube.com/user/marinstatlectures, or Fast Lane to Learning R at github.com//matloff/fasteR by Norm Matloff. Or look at swirlstats.com for an interactive way to learn R. Those who have used SPSS or SAS before will profit from R for SAS and SPSS Users by Robert Muenchen. A current list of R books on amazon.com may be found at amzn.to/15URiF6. stats.idre.ucla.edu/r/ and www.introductoryr.co.uk/R_Resources_for_Beginners.html are useful web sites. An excellent resource is R for Data Science by Grolemund and Wickham. See also R in Action, second ed. by Robert Kabacoff. The online open source book on statistical modeling by Legler and Roback at bookdown.org/roback/bookdown-bysh contains a lot of R code. Jenny Bryan’s STAT 545 Data Wrangling, Exploration, and Analysis with R course at stat545.com is an excellent resource. stackoverflow.com/tags/r is the best place for asking questions about the language and for learning from answers to past questions asked (see also the R-help email list).

Three of the best ways to learn how to analyze data in R quickly are

1. Avoid importing and manipulating data, instead using the R readRDS function to load datasets that are already annotated and analysis-ready (see R Workflow for information about importing your own datasets)
2. Use example R scripts as analysis templates
3. Use RStudio (rstudio.org) to run R On the first approach, the R Hmisc package’s getHdata function finds datasets in https://hbiostat.org/data, downloads them, and load()s them in your R session. These notes use only datasets available via this mechanism. These datasets are fully annotated with variable labels and units of measurements for many of the continuous variables. Concerning analysis scripts, some complete analysis script tamplates have been collected on github.com/harrelfe/rscripts and the R Hmisc package has a function getRs to download these scripts and to automatically populate an RStudio script editor window with the script. Many of the scripts are in RMarkdown format for use with the R knitr package to allow mixing of text and R code to make reproducible reports.

The RMarkdown scripts accessed through getRs use a template that makes the result part of a reproducible research process by documenting the versions of R and attached packages at the end of the report.

1.3 Setting up R

Before running examples in these notes and R markdown example scripts, you need to do the following:

1. Make sure your operating system is up to date enough to run the most current version of R at www.r-project.org. For Mac you must have OS X Maverick or later.
2. Install R from www.r-project.org or upgrade your installation of R to the latest version.
3. Install Quarto from quarto.org if you don’t want to use the version of Quarto that is provided automatically with RStudio
4. Install RStudio from rstudio.org or update your RStudio to the latest version.
5. Have RStudio install the Hmisc and rms packages (which will make RStudio install several other packages). For packages you had installed previously, make sure you update them to have the latest versions.

Here are some examples of how getRs is used once you load the Hmisc package using a menu or by typing require(Hmisc) or library(Hmisc) in the console.

require(Hmisc)      # do this once per session (or library(Hmisc))
options(url.method='libcurl')    # sometimes needed if using Windows
getRs()             # list available scripts
getRs(browse='browser')  # open scripts contents in your web browser
scripts <- getRs()  # store directory of scripts in an object that can easily
                    # be viewed on demand in RStudio (right upper pane)
getRs('introda.r')  # download introda.r and open in script editor
getRs(cats=TRUE)    # list available major and minor categories
categories <- getRs(cats=TRUE)  # store results in a list for later viewing
getRs(cats='reg')   # list all scripts in a major category containing 'reg'
getRs('importREDCap.r', put='source')   # source() to define a function

You can also point your browser to github.com/harrelfe/rscripts/blob/master/contents.md to see the available scripts and categories, and to be able to click on links to see html report output.

To get started using R in RStudio to create reproducible annotated reports, finish the above configuration instructions and type the following in the RStudio console: getRs('descriptives.Rmd', put='rstudio'). The above the script editor window click on Render (if using Quarto) or Knit HTML.

1.4 Quarto

Quarto is a new way to build scientific reports and articles. It is a replacement for R Markdown but its syntax is largely compatible with R Markdown, so resources on learning R Markdown are See kbroman.org/knitr_knutshell/pages/Rmarkdown.html and print the R Markdown cheat sheet from www.rstudio.com/resources/cheatsheets. For more advanced R Markdown usage see the excellent video by Tom Mock.

Quarto has you put a yaml (“yet another markup language”) header at the start of the document. When you start a new Quarto document with RStudio, RStudio will create a simple header. A more detailed template is here.

The R knitr package is automatically used to run the report and insert graphics and text output into the report at appropriate slots. It is best to specify a name for each chunk, and you must use unique names. Each R code chunk must begin exactly with ```{r …} and the chunk name is the first set of characters that appear after the space after r. Here are some example chunk headers. Chunk names must not contain a space.

```{r descriptives}
```{r anova}
```{r anova-y1}
```{r anova_y1}
```{r acidity_plot}
```{r plot_residuals}
```{r}

The last line indicates that you wish knitr to create the chunk name using a counter.

After the chunk header there are many directives to Quarto to allow control of formatting and to create figure cross-referencing labels and captions. More dtails are here.

1.5 Debugging R Code

When using RStudio and knitr/Quarto/RMarkdown, it is best to debug your commands a piece at a time. The fastest way to do this is to go to some line inside your first chunk and click the green C just above and to the right of your script. Click on then on Run Next Chunk. Shortcut keys for these are Ctrl+Alt+C and Ctrl+Alt+N (Command+Option+C and Command+Option+N for Mac). You can also click on a single line of code and run it by clicking on Run.

Whenever you get a strange execution error it is sometimes helpful to show the history of all the function calls leading to that error. This is done by typing traceback() at the command prompt.

1.6 Importing Other Datasets

Most of the work of getting some data sources ready for analysis involves reshaping datasets from wide to tall and thin, recoding variables, and merging multiple datasets. R has first-class capabilities for all of these tasks but this part of R is harder to learn, partly because there are so many ways to accomplish these tasks in R. Getting good variable names, variable labels, and value labels, can also be tedious but is highly worth the time investment. See R Workflow for detailed information about importing various types of files, and recoding and manipulating data after importing them.

Sometimes the dataset to read into R is very small and can be defined within the report. Here is an example.

# What is between data <- .. and ') is exactly like an external .csv file
data <- textConnection('
Age in Years,sex,race,visit date,m/s
23,m,w,10/21/2014,1.1
14,f,b,10/22/2014,1.3
,f,w,10/15/2014,1.7
')
require(Hmisc)
d <- csv.get(data, lowernames=TRUE, datevars='visit.date',
             dateformat='%m/%d/%Y')
close(data)  # close the textConnection
# lowernames=TRUE: convert variable names to lower case
# Omit dateformat if dates are in YYYY-MM-DD format
contents(d)

---

Data frame:d

3 observations and 5 variables, maximum # NAs:1  

---

Name	Labels	Class	Storage	NAs
age.in.years	Age in Years	integer	integer	1
sex	sex	character	character	0
race	race	character	character	0
visit.date	visit date	Date	double	0
m.s	m/s	numeric	double	0

---

d

  age.in.years sex race visit.date m.s
1           23   m    w 2014-10-21 1.1
2           14   f    b 2014-10-22 1.3
3           NA   f    w 2014-10-15 1.7

In the contents output above you can see that the original column names have been placed in the variable labels, and the new names have periods in place of blanks or a slash, since these characters are illegal in R names.

You can have as the first argument to csv.get not only a file name but a URL to a file on the web. You can also specify delimiters other than commas.

Also see the excellent tutorial on importing from Excel found at www.r-bloggers.com/r-tutorial-on-reading-and-importing-excel-files-into-r.

The Hmisc upData function may be used to rename variables and provide variable and value labels and units of measurement. Here is another example where there is a junk variable to delete after importing, and a categorical variable is coded as integers and need to have value labels defined after importing. We show how csv.get automatically renamed one illegal (to R) variable name, how to redefine a variable label, and how to define the value labels. Suppose that file test.csv exists in our project directory and has the following contents.

age,sys bp,sex,junk,state
23,140,male,1,1
42,131,female,2,1
45,127,female,3,2
37,141,male,4,2

Now import and modify the file.

require(Hmisc)
d <- csv.get('test.csv')
names(d)   # show names after modification by csv.get

[1] "age"    "sys.bp" "sex"    "junk"   "state"

contents(d)  # show labels created by csv.get

---

Data frame:d

4 observations and 5 variables, maximum # NAs:0  

---

Name	Labels	Class	Storage
age	age	integer	integer
sys.bp	sys bp	integer	integer
sex	sex	character	character
junk	junk	integer	integer
state	state	integer	integer

---

d <- upData(d,
            state=factor(state, 1:2, c('Alabama','Alaska')),
            rename=c(sys.bp='sbp'),
            labels=c(age = 'Age',
                     sbp = 'Systolic Blood Pressure'),
            drop='junk',   # for > 1: drop=c('junk1','junk2',...)
   units=c(sbp='mmHg'))

Input object size:   4040 bytes;     5 variables     4 observations
Renamed variable     sys.bp     to sbp
Modified variable   state
Dropped variable    junk
New object size:    3608 bytes; 4 variables 4 observations

contents(d)

---

Data frame:d

4 observations and 4 variables, maximum # NAs:0  

---

Name	Labels	Units	Levels	Class	Storage
age	Age			integer	integer
sbp	Systolic Blood Pressure	mmHg		integer	integer
sex	sex			character	character
state			2		integer

---

Category Levels

state

Alabama

Alaska

describe(d)

d

4 Variables   4 Observations

---

age: Age

n	missing	distinct	Info	Mean	pMedian	Gmd
4	0	4	1	36.75	38.25	11.83

 Value        23   37   42   45
 Frequency     1    1    1    1
 Proportion 0.25 0.25 0.25 0.25

For the frequency table, variable is rounded to the nearest 0

---

sbp: Systolic Blood Pressure mmHg

n	missing	distinct	Info	Mean	pMedian	Gmd
4	0	4	1	134.8	134.8	8.5

 Value       127  131  140  141
 Frequency     1    1    1    1
 Proportion 0.25 0.25 0.25 0.25

For the frequency table, variable is rounded to the nearest 0

---

sex

n	missing	distinct
4	0	2

 Value      female   male
 Frequency       2      2
 Proportion    0.5    0.5

---

state

n	missing	distinct
4	0	2

 Value      Alabama  Alaska
 Frequency        2       2
 Proportion     0.5     0.5

---

dim(d); nrow(d); ncol(d); length(d)  # length is no. of variables

[1] 4 4

[1] 4

[1] 4

[1] 4

For tiny datasets it is easiest to define them as follows:

d <- data.frame(age=c(10,20,30), sex=c('male','female','male'),
                sbp=c(120,125,NA))

Large files may be stored in R binary format using saveRDS(..., compress='xz'), which creates an incredibly compact representation of the data in a file usually suffixed with .rds. This allows extremely fast loading of the data frame in your next R session using readRDS(...).

1.7 Suggestions for Initial Data Look

The datadensity function in the Hmisc package gives an overall univariable graphical summary of all variables in the imported dataset. The contents and describe functions are handy for describing the variables, labels, number of NAs, extreme values, and other values. R Workflow has many other approaches for the initial data look.

1.8 Operating on Data Frames

One of the most common operations is subsetting. In the following example we subset on males older than 26.

young.males <- subset(d, sex == 'male' & age > 26)
# If you want to exclude rows that are missing on sex or age:
young.males <- subset(d, sex == 'male' & age > 26 & ! is.na(sex) &
                        ! is.na(age))
# f <- lrm(y ~ sex + age, data=subset(d, sex == 'male' & ...))
# f <- lrm(y ~ sex + age, data=d, subset=sex == 'male' & age > 26 ...)

R Development Team. (2020). R: A language and environment for statistical computing. R Foundation for Statistical Computing; www.r-project.org. http://www.R-project.org
